Long Radius Elbows (LR)

Description Manufacturers & Suppliers of Long Radius Elbows, Buy 45 Degree, 90 Degree & 180 Degree Long Radius Elbows METLINE is one of the leading manufacturer, exporter and supplier of stainless steel long radius elbows, carbon steel long radius elbows, alloy steel long radius elbows, cupro nickel long radius elbows, nickel alloy long radius elbows and duplex steel pipe long radius elbow in size range of 1/2″ to 60″. At Metline, elbows are manufactured in accordance with national and international product standards, while we can also produce bends as per special specifications of our customers. In case of custom size fabricated pipe elbows, the welding done is carried out by qualified personnel. Seamless Long Radius Elbows Seamless long radius elbows are manufactured from seamless pipes and tube by hot or cold extrusion, forming and machining process. We are a leading supplier and manufacturer of seamless long radius elbow fittings in India. Most of the seamless elbow pipe fittings in standard sizes and grades are available ex-stock for immediate supply to our customers. Welded or Fabricated Long Radius Elbows Seam welded long radius elbows are produced from hot rolled steel pipes. As per customer requirements, we can also manufacture and offer pipe elbows manufactured from hot rolled plates, formed into half shells or segments and then welded on the seams. Elbows are categorized based on various design features such as below: Long Radius (LR) Elbow is also called LR elbow – means the radius is 1.5 times the pipe diameter L/R 45°Elbow: Long radius 45 degree elbow changes the direction by 45 degrees. L/R 90°Elbow: Long radius 90 degree elbow changes the direction by 90 degrees. L/R 180°Elbow: Long Radius 180 degree return bend allows complete reversal of flow. Short Radius (SR) Elbow is also called SR elbow, – means the radius is 1.0 times the pipe diameter Short radiu 45°Elbow: Short radius 45° elbow changes the direction by 45 degrees. Short radius 90°Elbow: Short Radius 90° elbow is same as LR90 except for the measurement between end of elbow to center line is 1 x NPS. Short radius 180° Elbow: Short Radius 180° return bend allows complete reversal of flow Elbows are generally used, when the radius required is 1D, 1.5D or 2D, but when the curvature exceeds 3D, bends are most commonly utilized. Pipe Bends Production & Supply Range Product Long Radius Elbows Brand METLINE Outside Diameter Seamless Pipe Bends Welded Pipe Bends 1/2″~24″, DN15~DN600 6″~60″, DN150~DN1500 Wall Thickness 2mm ~ 200mm Bend Radius R=3D ~ 10D Product Angle 0°~180° Materials Carbon Steel: ASTM/ASME A234 WPB, WPC Alloy Steel: ASTM/ASME A234 WP 1-WP 12-WP 11-WP 22-WP 5-WP 91-WP 911 Stainless Steel:ASTM/ASME A403 WP 304-304L-304H-304LN-304N ASTM/ASME A403 WP 316-316L-316H-316LN-316N-316Ti ASTM/ASME A403 WP 321-321H ASTM/ASME A403 WP 347-347H Low-Temperature Steel: ASTM/ASME A402 WPL 3-WPL 6 High-Performance Steel: ASTM/ASME A860 WPHY 42-46-52-60-65-70 Production Technique Forging, Pressing, Bending Application Power Generation, Oil and Gas, Petrochemical, Chemical, Shipbuilding, Heating, Paper making, Metallurgy Packing Wooden Pallets, or Wooden Boxes Test Certificates EN 10204 3.1 Inspection Buyer Inspection or Third Party Inspection Allowed
